Case study · Franklin, TN · Aug 22, 2025
A modern farmhouse new build in Berry Farms (Franklin, 37064) — the architect specified 24-gauge Galvalume standing-seam metal on the entire main mass, with a CertainTeed Landmark Pro architectural asphalt on the wrapped front porch. We coordinated with the builder for a 5-day install that landed two days ahead of the substantial-completion target.
Squares
46 sq metal + 8 sq asphalt = 5,400 sq ft total
Pitch
9/12 main, 4/12 porch
Access
Scaffolding required for the rear two-story face
Tear-off
None — new build over fresh OSB
CertainTeed (Drexel Metals)
24-gauge is the heaviest gauge commonly used in residential — twice as resistant to denting as 26-ga. Galvalume is the aluminum-zinc coating that resists rust and rates 40+ year life. Charcoal Gray was the architect's spec to read 'dark farmhouse' on the south elevation.
CertainTeed
Color-matched to the metal — both Charcoal Gray, so the porch reads continuous with the main mass from grade. Landmark Pro is CertainTeed's mid-tier architectural with a 50-year limited warranty.
CertainTeed
Full coverage at all valleys, eaves, around penetrations, and at the metal-to-asphalt transition (which is a known leak point if under-shielded).
Drexel Metals
Mechanical snap-lock seams, no field crimping. Panels concealed-fastened (clips, no exposed screw heads). Hidden-fastener systems carry 40+ year leak warranties; exposed-fastener systems do not.
Drexel Metals
All clips and substrate fasteners hidden under the seam. Zero exposed fasteners means zero gasket-failure points — the #1 source of leaks on cheaper exposed-fastener metal roofs.
Builder coordination + scaffolding
Coordinated start date with the builder's substantial-completion target. Scaffolding set on the rear two-story face the day before install.
Underlayment + I&W shield, main mass
Full synthetic underlayment over the entire mass. I&W shield in valleys, at eaves, and around all penetrations including the chimney chase.
Standing-seam panel install
Custom-cut panels run-to-length from the truck. Concealed clips set every 18" up the slope. Snap-lock seams engaged by hand — no crimping tool, no exposed fasteners.
Asphalt porch + transitions
Wrapped front porch installed in Landmark Pro Charcoal Gray. Metal-to-asphalt transition flashing set with double I&W shield overlap (this is the leak point on most mixed-material roofs).
Final flashings + walk + builder handoff
Ridge cap, hip cap, chimney counter-flashing. Magnetic sweep, scaffolding removed. Builder substantial-completion walk; signed off, no punch-list items.
Drexel-supplied 24-ga Galvalume carries CertainTeed's longest panel warranty. Covers manufacturing defects, premature corrosion, and finish degradation.
Standard CertainTeed limited warranty on the Landmark Pro architectural shingle. Transferable once.
Anything we installed — metal panels, seams, flashings, transitions, asphalt porch, ridge cap — we cover for as long as the original owner owns the home.
Drexel's hidden-fastener system carries a 40-year no-leak warranty. Exposed-fastener metal does not qualify.
Outcome
Insurance + warranty + sign-off.
Substantial-completion two days ahead of builder schedule. No punch-list items at builder walk. 11-month follow-up: no callbacks, no leaks, no panel issues. Homeowner referred two neighbors who broke ground in 2026.
On new builds, the cost-premium for hidden-fastener 24-ga standing seam over exposed-fastener 26-ga is about 35% — but the warranty differential (40-year leak warranty vs. typically 20-year on exposed-fastener) and the lifetime differential (40+ years vs. typically 25) make it the right answer if you're going to own the home for 15+ years.
